74266 XNOR Gate IC
1. Function: Quad 2-input XNOR
2. Logic Family: 74LS/74HC compatible
3. Supply Voltage: 5V (typical)
4. Number of Gates: 4
5. Propagation Delay: ~10-20 ns
Apple Shopping Event
20,80 EGP
Payment Methods:
Description
The 74266 XNOR gate IC is a quadruple 2-input XNOR logic gate, part of the standard 74LS or 74HC logic family. It provides the logical equivalence function, producing a high output when both inputs are the same (both high or both low). This chip is fundamental for digital logic design, used in comparators, parity checkers, and arithmetic circuits where equality detection is necessary.
Each of the four independent gates processes two digital inputs and outputs a single logic level. The device is typically powered by a 5V supply (for TTL versions) and offers standard noise margins and propagation delays compatible with other TTL logic devices. Its DIP or surface-mount packaging ensures easy integration into breadboards and printed circuit boards for educational and prototyping purposes.
- Quad 2-input XNOR gates
- Package type: DIP or SMD
- Standard 5V TTL or CMOS compatibility
- Low power consumption
- High noise immunity
- Typical propagation delay: ~10-20 ns
- Widely used in equality comparison circuits
- Industry-standard 74266 pinout
نظرة عامة ومواصفات المنتج — بالعربية
74266 xnor متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم 7400-series، بسعر 20,80 EGP. كود المنتج لدينا: EK2062. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Logic Function: XNOR (Quad 2-input)
- Supply Voltage (Vcc): 5V (typical)
- Input Voltage: TTL/CMOS levels
- Output Type: Standard TTL
- Propagation Delay: ~10-20 ns (depending on version)
- Operating Temperature: 0°C to 70°C (industrial range)
- Package Type: DIP-14 (or SOIC-14)
- Number Of Gates: 4
منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.
تصفّح المزيد من 7400-series في إكوسترا.
Specification
Specification
| WeightWeight | 1 g |
|---|---|
| Dimensions | 1 × 0,6 × 0,5 cm |
| Logic Function | XNOR (Quad 2-input) |
| Supply Voltage (VCC) | 5V (typical) |
| Input Voltage | TTL/CMOS levels |
| Output Type | Standard TTL |
| Propagation Delay | ~10-20 ns (depending on version) |
| Operating Temperature | 0°C to 70°C (industrial range) |
| Package Type | DIP-14 (or SOIC-14) |
| Number of Gates | 4 |
| Fan-out | Standard (10 LSTTL loads) |
