CD4572 Hex Gate
CD4572 Hex Gate
1. Function: Hex Gate (mixed logic functions)
2. Supply Voltage: 3V to 18V DC
3. Logic Family: 40xx-series CMOS
4. Package Type: 14-pin DIP
5. Features: Multiple gate types integrated
6. Power: Low quiescent current
Apple Shopping Event
13,00 EGP
Payment Methods:
Description
The CD4572 is a hex gate IC from the 40xx-series CMOS family, integrating multiple logic functions in a single package. This device combines NOT gates, AND gates, and NAND gates to provide flexible logic implementation for a variety of combinatorial and interface applications.
Operating from 3V to 18V, the CD4572 offers the low quiescent current and high noise immunity characteristic of 40xx-series CMOS logic. The mixed gate configuration reduces component count in designs requiring multiple logic functions without the need for separate single-gate packages, simplifying PCB layout and BOM management.
- Multiple logic functions integrated in one package
- Wide supply voltage: 3V to 18V DC
- Low CMOS power consumption
- High noise immunity for robust system design
- Standard 14-pin DIP package
- Suitable for space-efficient logic implementations
- Reliable through-hole component for prototyping
نظرة عامة ومواصفات المنتج — بالعربية
CD4572 Hex Gate متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم 40xx-series وSemiconductor ICs، بسعر 13,00 EGP. كود المنتج لدينا: EK1236. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Function: Hex Gate (mixed NOT/AND/NAND)
- Supply Voltage: 3V to 18V DC
- Number Of Gates: 6
- Package Type: 14-pin DIP
- Logic Family: 40xx-series CMOS
- Technology: CMOS
- طريقة التثبيت: Through-Hole
- الوزن: 1 g
منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.
تصفّح المزيد من 40xx-series في إكوسترا.
Specification
Specification
| WeightWeight | 1 g |
|---|---|
| Dimensions | 1 × 0,6 × 0,5 cm |
| Function | Hex Gate (mixed NOT/AND/NAND) |
| Supply Voltage | 3V to 18V DC |
| Number of Gates | 6 |
| Package Type | 14-pin DIP |
| Logic Family | 40xx-series CMOS |
| Technology | CMOS |
| Mounting Type | Through-Hole |
