PCB Line FR2 (7X9 cm2)
PCB Line FR2 (7x9cm)
1. Material: FR2 (Phenolic Paper)
2. Dimensions: 7cm x 9cm
3. Track Configuration: Continuous Copper Lines (Stripboard)
4. Hole Pitch: 2.54mm
5. Mounting Holes: 4 Pre-drilled Corner Holes
Apple Shopping Event
18,00 EGP
Payment Methods:
Description
This PCB Line FR2 board is a stripboard-style prototyping board made from FR2 phenolic paper/synthetic resin, featuring continuous copper line strips on the bottom layer rather than isolated pads.
Measuring 7cm x 9cm (70mm x 90mm) with a standard FR2 thickness of about 1.2mm, the board uses a 2.54mm hole pitch with 1.0mm hole diameter, matching standard through-hole component spacing.
Four pre-drilled corner mounting holes make it easy to secure in an enclosure, and its continuous copper strips suit permanent breadboard-layout transfers, bus-line soldering, and STEM educational projects.
Features:
- Continuous copper line/strip layout (stripboard)
- Single-sided copper on FR2 substrate
- Board size: 7cm x 9cm
- Standard 2.54mm hole pitch
- 4 pre-drilled corner mounting holes
- Suited for breadboard layout transfers and bus-line soldering
نظرة عامة ومواصفات المنتج — بالعربية
PCB Line FR2 (7X9 cm2) متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Breadboard and Zero PCBs، بسعر 18,00 EGP. كود المنتج لدينا: EK1458. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Product Type: Prototyping Stripboard / Line PCB
- الخامة: FR2 (Phenolic Paper / Synthetic Resin)
- الأبعاد: 7cm x 9cm (70mm x 90mm)
- Board Thickness: ~1.2mm
- Layer Count: Single-Sided (Copper tracks on bottom)
- Track Configuration: Continuous Copper Lines / Strips
- Hole Pitch: 2.54mm (0.1")
- Hole Diameter: 1.0mm
هذا المنتج مناسب لمشاريع الأردوينو (Arduino) و ESP32 و Raspberry Pi، ومشاريع الروبوتات وإنترنت الأشياء والتعليم الهندسي. جميع القطع مفحوصة قبل الشحن.
تصفّح المزيد من Breadboard and Zero PCBs في إكوسترا.
Specification
Specification
| WeightWeight | 10 g |
|---|---|
| Dimensions | 5 × 4 × 2 cm |
| Product Type | Prototyping Stripboard / Line PCB |
| Material | FR2 (Phenolic Paper / Synthetic Resin) |
| Dimensions | 7cm x 9cm (70mm x 90mm) |
| Board Thickness | ~1.2mm |
| Layer Count | Single-Sided (Copper tracks on bottom) |
| Track Configuration | Continuous Copper Lines / Strips |
| Hole Pitch | 2.54mm (0.1″) |
| Hole Diameter | 1.0mm |
| Mounting Holes | 4 Pre-drilled corner mounting holes |
