Water Level Indicator Kit
1. Kit Type: Unassembled (DIY)
2. Sensor Type: Probe Electrodes (Conductive)
3. Number of Levels: 1–5 Levels
4. Power Supply: 3–12VDC
Apple Shopping Event
20,00 EGP
Payment Methods:
Description
This Water Level Indicator Kit is an unassembled DIY electronics kit that detects and indicates water level using probe electrodes for conductive water sensing, requiring the builder to solder the components together.
The kit typically displays 1–5 levels via LED indicators, with an optional buzzer depending on the kit variant, and runs on 3–12VDC with low current consumption depending on the number of active LEDs/buzzer. Main components typically include a PCB, resistors, capacitors, transistors or an IC, LEDs, an optional buzzer, and probe wires/pins.
Soldering tools, a battery or adapter, and an enclosure are not included, so this kit is aimed at builders comfortable with through-hole soldering who want to assemble the circuit themselves for tank level monitoring, overflow warning, or educational purposes.
Features:
- Unassembled DIY kit (soldering required)
- Conductive probe-based water level sensing
- 1–5 level LED indication
- Optional buzzer (kit dependent)
- Operating voltage: 3–12VDC
- Low current consumption
- Suited for tank monitoring and educational projects
نظرة عامة ومواصفات المنتج — بالعربية
water level indicator kit متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم DIY Learning and Robot Kits، بسعر 20,00 EGP. كود المنتج لدينا: EK1388. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Product Type: Water Level Indicator Kit (DIY)
- Kit Type: Unassembled (Not Assembled)
- Function: Water Level Detection / Indication
- Indication Type: LED Indicators / Optional Buzzer
- Number Of Levels: 1–5 Levels
- Sensor Type: Probe Electrodes (Conductive)
- Power Supply: 3–12VDC
- Current Consumption: Low
منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.
تصفّح المزيد من DIY Learning and Robot Kits في إكوسترا.
Specification
Specification
| WeightWeight | 10 g |
|---|---|
| Dimensions | 5 × 4 × 2 cm |
| Product Type | Water Level Indicator Kit (DIY) |
| Kit Type | Unassembled (Not Assembled) |
| Function | Water Level Detection / Indication |
| Indication Type | LED Indicators, Optional Buzzer |
| Number of Levels | 1–5 Levels |
| Sensor Type | Probe Electrodes (Conductive) |
| Power Supply | 3–12VDC |
| Current Consumption | Low |
| Main Components | PCB, Resistors, Capacitors, Transistors/IC, LEDs, Buzzer (optional), Probe wires/pins |
| Not Included | Soldering Tools, Battery/Adapter, Enclosure |
| Mounting | Through-Hole (DIY Soldering) |
