6800uF 10V Radial Electrolytic Capacitor
6800uF 10V Radial Electrolytic Capacitor
1. Capacitance: 6800µF
2. Voltage Rating: 10V DC
3. Capacitance Tolerance: ±20% (typical)
4. Mounting Type: Through-Hole Radial
5. Operating Temperature: -40°C to +85°C
6. Polarity: Polarized (marked case)
Apple Shopping Event
1,00 EGP
Payment Methods:
Description
This 6800µF 10V radial electrolytic capacitor offers a balanced capacitance value for moderate-power DC filtering and decoupling applications. The 10V DC rating is well-suited for 5V and 3.3V systems, providing ample voltage headroom while delivering substantial charge storage for transient load support and ripple attenuation.
The capacitor features a polarized aluminum electrolytic construction in a radial can package, with leads arranged for vertical through-hole PCB placement. This format combines high volumetric efficiency with straightforward automated or hand assembly, making it a practical choice for both prototyping and production runs.
- 6800µF nominal capacitance for bulk filtering
- 10V DC working voltage for low-voltage rails
- Aluminum electrolytic construction with polarized marking
- Radial lead configuration for PCB mounting
- Effective ripple current handling capability
- Low ESR for improved transient response
- Rated for -40°C to +85°C operation
- Cost-effective solution for power supply smoothing
نظرة عامة ومواصفات المنتج — بالعربية
6800uF 10V Radial Electrolytic Capacitor متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Capacitor، بسعر 1,00 EGP. كود المنتج لدينا: EK1276. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Capacitance: 6800µF
- Voltage Rating: 10V DC
- Capacitance Tolerance: ±20%
- طريقة التثبيت: Radial Through-Hole
- Polarity: Polarized
- Operating Temperature Range: -40°C to +85°C
- Package: Radial Can
- Terminal Type: Radial Leads
منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.
تصفّح المزيد من Capacitor في إكوسترا.
Specification
Specification
| WeightWeight | 10 g |
|---|---|
| Dimensions | 1,3 × 1,3 × 2,5 cm |
| Capacitance | 6800µF |
| Voltage Rating | 10V DC |
| Capacitance Tolerance | ±20% |
| Mounting Type | Radial Through-Hole |
| Polarity | Polarized |
| Operating Temperature Range | -40°C to +85°C |
| Package | Radial Can |
| Terminal Type | Radial Leads |
