Arduino uno lenardo
- ATmega32u4 microcontroller with native USB support
- Acts as USB HID device – keyboard, mouse, etc.
- 20 I/O pins – 7 PWM outputs, 12 analog inputs
- Micro-USB port for programming & power
- 16 MHz crystal oscillator
- 32KB flash, 2.5KB SRAM, 1KB EEPROM
- Ideal for USB emulation & automation projects
- Fully Arduino IDE compatible
Apple Shopping Event
550,00 EGP
Payment Methods:
Description
The Arduino Leonardo R3 is a powerful ATmega32u4-based microcontroller development board offering advanced capabilities for USB-based applications. Unlike traditional Arduino boards, the Leonardo communicates directly via USB using its built-in USB controller—allowing it to emulate a keyboard, mouse, game controller, or other HID device natively.
It features 20 digital I/O pins (7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, micro-USB interface, ICSP header, and reset button. It’s fully compatible with the Arduino IDE and is ideal for robotics, sensors, automation, and interactive projects where USB emulation is needed.
Key Features
-
Microcontroller: ATmega32u4 with native USB support
-
20 digital I/O pins (7 PWM, 12 analog inputs)
-
16 MHz clock speed
-
Acts as a USB HID device (keyboard, mouse, etc.)
-
32KB flash memory (4KB used by bootloader)
-
Micro-USB for programming and power
-
Compatible with Arduino IDE
-
Perfect for USB interface and automation projects
Specifications
| Parameter | Value |
|---|---|
| Microcontroller | ATmega32u4 |
| Operating Voltage | 5V |
| Input Voltage (recommended) | 7–12V |
| Digital I/O Pins | 20 |
| PWM Channels | 7 |
| Analog Input Pins | 12 |
| Flash Memory | 32KB (4KB used by bootloader) |
| SRAM | 2.5KB |
| EEPROM | 1KB |
| Clock Speed | 16 MHz |
| USB Interface | Native USB (Micro-USB port) |
| Communication Protocols | UART, SPI, I2C |
Package Includes
-
1 × Arduino Leonardo R3 Development Board
نظرة عامة ومواصفات المنتج — بالعربية
Arduino uno lenardo متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Arduino Boards وDevelopment Boards، بسعر 550,00 EGP. كود المنتج لدينا: arduino-uno-lenardo. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Product Type: Development Board
- Pa Model: Arduino Leonardo
- المتحكم الدقيق: ATmega32u4
- Operating Voltage (V): 5
- Input Voltage Range (V): 7–12
- Clock Speed (Mhz): 16
- Digital I/O Pins: 20
- Pwm Pins: 7
هذا المنتج مناسب لمشاريع الأردوينو (Arduino) و ESP32 و Raspberry Pi، ومشاريع الروبوتات وإنترنت الأشياء والتعليم الهندسي. جميع القطع مفحوصة قبل الشحن.
تصفّح المزيد من Arduino Boards في إكوسترا.
Specification
Specification
| WeightWeight | 25 g |
|---|---|
| Dimensions | 6,86 × 5,34 × 1,5 cm |
| Product Type | Development Board |
| Model | Arduino Leonardo |
| Microcontroller | ATmega32u4 |
| Operating Voltage (V) | 5 |
| Input Voltage Range (V) | 7–12 |
| Clock Speed (MHz) | 16 |
| Digital I/O Pins | 20 |
| PWM Pins | 7 |
| Analog Input Pins | 12 |
| Length (mm) | 68.6 |
| Width (mm) | 53.3 |
| Height (mm) | 15 |
| Weight (g) | 25 |
| Interface | Micro-USB |
| USB Communication | Native USB |
| Compatibility | Arduino IDE |
| Architecture | AVR |
| Special Feature | Can act as Keyboard / Mouse (HID) |
| Application | Robotics, HID Projects, Embedded Systems, DIY Electronics |
