BC547 NPN Transistor – DIP Package

NPN transistor in DIP package
Max collector current: 100 mA
Max collector-emitter voltage: 45 V
High gain (hFE up to 800)
Low noise for audio and signal applications
Common for general-purpose amplification and switching

SKU: EK819 Categories: Basic Electronic Components, Transistor Tags: Basic Electronic Components, Transistor

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

1,00 EGP

Compare

12 People watching this product now!

Payment Methods:

Description

The BC547 is a general-purpose NPN bipolar junction transistor (BJT) in a DIP (Dual In-line Package) design, ideal for low-power signal amplification and switching applications. Its compact size and versatility make it a popular choice in a wide range of electronic circuits.

Key Features:

Type: NPN Bipolar Junction Transistor (BJT)
Package: TO-92 (DIP)
Voltage Ratings:
- Collector-Emitter Voltage (V_CEO): 45V
- Collector-Base Voltage (V_CBO): 50V
- Emitter-Base Voltage (V_EBO): 6V
Current Ratings:
- Collector Current (I_C): 100mA max
Gain (h_FE): 110 to 800
Applications: Signal amplification, switching, and general-purpose use

Pin Configuration:

Collector (C) – Connected to the load
Base (B) – Controls the transistor operation
Emitter (E) – Common ground/reference

Applications:

Low-power amplifiers
Signal processing
Switching circuits
Hobby and DIY electronics

The BC547 is a reliable and affordable transistor suitable for both educational and professional electronic projects.

نظرة عامة ومواصفات المنتج — بالعربية

BC547 NPN Transistor - DIP Package متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Basic Electronic Components وTransistor، بسعر 1,00 EGP. كود المنتج لدينا: EK819. المنتج متوفر في المخزون وجاهز للشحن الفوري لكل محافظات مصر مع إمكانية الدفع عند الاستلام.

أهم المواصفات الفنية:

Product Name: BC547 NPN Transistor – DIP Package
Transistor Type: NPN Bipolar Junction Transistor
Package Type: TO-92 (DIP)
Collector Emitter Voltage (Vce): 45V
Collector Base Voltage (Vcb): 50V
Emitter Base Voltage (Veb): 6V
Collector Current (Ic): 100mA (max)
Power Dissipation: 500mW (approx.)

منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.

تصفّح المزيد من Basic Electronic Components في إكوسترا.

Specification

WeightWeight	1 g
Dimensions	0,5 × 0,5 × 0,45 cm
Product Name	BC547 NPN Transistor – DIP Package
Transistor Type	NPN Bipolar Junction Transistor
Package Type	TO-92 (DIP)
Collector-Emitter Voltage (Vce)	45V
Collector-Base Voltage (Vcb)	50V
Emitter-Base Voltage (Veb)	6V
Collector Current (Ic)	100mA (max)
Power Dissipation	500mW (approx.)
DC Current Gain (hFE)	110–800 (depending on subtype A/B/C)
Transition Frequency (ft)	100MHz (typical)
Polarity	NPN
Applications	Switching, Amplification, Signal Processing, General Electronics
Pin Configuration	Emitter–Base–Collector (E-B-C)
Dimension	5x4x3 mm (TO-92 body approx.)
