ESP32 3.5″ TFT Touch Screen Development Board (LVGL)
ESP32 3.5″ TFT Touch Screen Development Board (LVGL)
1. Controller: ESP32-S3 (Dual-Core)
2. Screen Size: 3.5″ IPS TFT, 320×480
3. Touch Type: Capacitive Multi-touch
4. Memory: 8MB PSRAM | 16MB Flash
5. Connectivity: Wi-Fi 802.11 b/g/n | Bluetooth 5.0
Apple Shopping Event
1.900,00 EGP
Payment Methods:
Description
The ESP32 3.5″ TFT Touch Screen Development Board is an HMI-focused dev board built around the dual-core ESP32-S3 (ESP-WROOM-32) controller, paired with a 3.5-inch IPS TFT LCD at 320×480 resolution and capacitive multi-touch support.
Onboard memory includes 8MB of PSRAM and 16MB of flash, sized specifically to handle LVGL graphics rendering for smooth, responsive touch UIs. Wireless connectivity covers 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5.0 (BLE).
Interfaces include USB Type-C for power and programming, a MicroSD/TF card slot, and UART, I2C, and SPI headers for expansion. It supports Arduino IDE, LVGL, MicroPython, and ESP-IDF, running on a 5V DC supply.
Features:
- ESP32-S3 dual-core controller
- 3.5″ IPS TFT capacitive touch display, 320×480 resolution
- 8MB PSRAM, 16MB flash for LVGL graphics
- Wi-Fi 802.11 b/g/n + Bluetooth 5.0 (BLE)
- USB Type-C power/programming
- MicroSD/TF card slot, UART/I2C/SPI interfaces
- Supports Arduino IDE, LVGL, MicroPython, ESP-IDF
نظرة عامة ومواصفات المنتج — بالعربية
ESP32 3.5" TFT Touch Screen Development Board (LVGL) متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Development Boards، بسعر 1.900,00 EGP. كود المنتج لدينا: EK2024. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Module Type: HMI Smart Display / Development Board
- Main Controller: ESP32-S3 (Dual-Core 32-bit) / ESP-WROOM-32
- Screen Size: 3.5 Inch
- Display Panel: IPS TFT LCD
- Resolution: 320 x 480 Pixels
- Touch Type: Capacitive Touch Screen (Multi-touch)
- Memory: 8MB PSRAM / 16MB Flash
- Wireless Connectivity: 2.4GHz Wi-Fi (802.11 b/g/n) / Bluetooth 5.0 (BLE)
هذا المنتج مناسب لمشاريع الأردوينو (Arduino) و ESP32 و Raspberry Pi، ومشاريع الروبوتات وإنترنت الأشياء والتعليم الهندسي. جميع القطع مفحوصة قبل الشحن.
تصفّح المزيد من Development Boards في إكوسترا.
Specification
Specification
| WeightWeight | 10 g |
|---|---|
| Dimensions | 5,5 × 2,8 × 1,2 cm |
| Module Type | HMI Smart Display / Development Board |
| Main Controller | ESP32-S3 (Dual-Core 32-bit) / ESP-WROOM-32 |
| Screen Size | 3.5 Inch |
| Display Panel | IPS TFT LCD |
| Resolution | 320 x 480 Pixels |
| Touch Type | Capacitive Touch Screen (Multi-touch) |
| Memory | 8MB PSRAM, 16MB Flash |
| Wireless Connectivity | 2.4GHz Wi-Fi (802.11 b/g/n), Bluetooth 5.0 (BLE) |
| On-Board Interfaces | USB Type-C, MicroSD/TF Card Slot, UART, I2C, SPI |
| Supported Frameworks | Arduino IDE, LVGL, MicroPython, ESP-IDF |
| Operating Voltage | 5V DC |
