L7924CV Voltage Regulator

The L7924CV is a negative fixed-voltage linear regulator, producing a regulated -24V output at up to 1A of continuous current. As part of the standard L79xx negative regulator family, it takes an unregulated negative input voltage and holds the output steady at -24V regardless of moderate input or load variation.

Negative regulators like this one are used in circuits that need a stable negative supply rail alongside a positive rail — common in op-amp circuits, audio equipment, and other analog electronics requiring dual-polarity power.

Features:
1. Fixed -24V negative output voltage
2. Rated up to 1A output current
3. Linear regulator (L79xx family)
4. Suited to dual-polarity analog power supplies
5. Simple, minimal external component design typical of L79xx regulators
