Bridge Rectifier ( 2A , 1000V )
-
2A current capacity
-
1000V reverse voltage tolerance
-
Compact full-bridge design
-
Ideal for AC to DC conversion
-
Suitable for power supplies, chargers, and electronics projects
Apple Shopping Event
5,00 EGP
Payment Methods:
Description
Bridge Rectifier (2A, 1000V)
The 2A 1000V Bridge Rectifier is a compact and efficient electronic component used to convert AC (alternating current) to DC (direct current). Capable of handling up to 2 Amps of current and withstanding reverse voltages up to 1000V, it is ideal for power supplies, battery chargers, LED drivers, and general electronic circuits.
This rectifier integrates four diodes in a full-bridge configuration within a single compact package, simplifying design and increasing reliability.
✅ Key Features:
-
Maximum Average Forward Current: 2A
-
Peak Reverse Voltage: 1000V
-
High Efficiency: Ensures minimal power loss
-
Compact Design: Saves PCB space
-
Reliable Operation: Encapsulated for protection from dust and moisture
-
Easy to Mount: Through-hole design for simple integration into circuits
📐 Specifications:
| Parameter | Value |
|---|---|
| Type | Bridge Rectifier |
| Max Average Forward Current | 2A |
| Peak Reverse Voltage (VRRM) | 1000V |
| Surge Current (IFSM) | Typically 50A (for 1 cycle) |
| Package Type | Common DIP/SIP or square type |
| Mounting Style | Through-Hole |
| Polarity | Standard bridge (+, −, AC, AC) |
| Operating Temperature | -55°C to +150°C |
⚙️ Applications:
-
AC to DC power supply circuits
-
LED drivers and lighting systems
-
Battery charging systems
-
Small appliances and DIY electronics
-
Low to medium current rectification
نظرة عامة ومواصفات المنتج — بالعربية
Bridge Rectifier ( 2A , 1000V ) متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Diode وElectronic Components وRectifiers، بسعر 5,00 EGP. كود المنتج لدينا: EK925. المنتج متوفر في المخزون وجاهز للشحن الفوري لكل محافظات مصر مع إمكانية الدفع عند الاستلام.
أهم المواصفات الفنية:
- Type: Bridge Rectifier
- Maximum Forward Current: 2 A
- Peak Reverse Voltage: 1000 V
- Forward Voltage Drop: 1.1 V (typical per diode)
- Package Type: KBPC / DIP / Through-Hole (depending on variant)
- Operating Temperature: -55°C to +150°C
- طريقة التثبيت: Through-Hole / PCB
- Applications: AC to DC Conversion, Power Supplies, Electronics Circuits, DIY Projects
منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.
تصفّح المزيد من Diode في إكوسترا.
Specification
Specification
| WeightWeight | 1 g |
|---|---|
| Dimensions | 2,2 × 2,2 × 1 cm |
| Type | Bridge Rectifier |
| Maximum Forward Current | 2 A |
| Peak Reverse Voltage | 1000 V |
| Forward Voltage Drop | 1.1 V (typical per diode) |
| Package Type | KBPC / DIP / Through-Hole (depending on variant) |
| Operating Temperature | -55°C to +150°C |
| Mounting Type | Through-Hole / PCB |
| Applications | AC to DC Conversion, Power Supplies, Electronics Circuits, DIY Projects |
| Package Contents | 1× Bridge Rectifier (2A, 1000V) |
