The LM2596 Step Down Buck Converter is a DC-DC converter module built around the LM2596S chip, switching at 150 KHz to step down an input of 4.0V–40V DC to a continuously adjustable output between 1.25V and 37V DC. The input must stay at least 1.5V above the target output for correct regulation.
Rated output current is 2A continuous, with a maximum of 3A when a heatsink is fitted, delivering up to 15W without additional cooling. Conversion efficiency reaches up to 92%. Onboard filtering comes from a 220µF 35V capacitor plus a 100µF 50V capacitor, paired with a 470 SMD inductor.
A 3-digit LED voltmeter display toggles between input and output voltage via a tactile push button, while a multi-turn potentiometer allows fine voltage adjustment. Screw terminal blocks connect both input and output sides.
Features:
LM2596S-based buck converter
150 KHz switching frequency
Output current: 2A rated, up to 3A with heatsink
Conversion efficiency up to 92%
Continuously adjustable output: 1.25V–37V DC
3-digit LED voltmeter with input/output toggle
Multi-turn potentiometer for precise voltage setting
Suited for battery charging and stepping down 12V/24V systems
🔌
