SolarCell 12V 125 mA
SolarCell 12V 125mA
1. Nominal Voltage: 12V
2. Rated Current: 125mA
3. Rated Power: 1.5W
4. Open Circuit Voltage: 18–22V
5. Short Circuit Current: 130–160mA
Apple Shopping Event
300,00 EGP
Payment Methods:
Description
This Solar Cell is a 12V nominal photovoltaic module rated for 125mA current output and 1.5W of power, converting sunlight into DC electricity for small battery-charging and DIY power applications.
At its typical operating point, the panel produces around 12V and 125mA (Vmp/Imp), while its open-circuit voltage (Voc) runs higher, typically 18–22V for a 12V-nominal panel design, and short-circuit current (Isc) typically falls between 130–160mA.
Best paired with a charge regulator when used for battery charging, this panel suits small DIY solar projects, off-grid sensor power, and general educational solar experiments.
Features:
- Nominal voltage: 12V
- Rated current: 125mA
- Rated power: 1.5W
- Open circuit voltage: 18–22V (typical)
- Short circuit current: 130–160mA (typical)
- DC output type
- Suited for battery charging with a regulator
نظرة عامة ومواصفات المنتج — بالعربية
SolarCell 12V 125 mA متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Power Supply، بسعر 300,00 EGP. كود المنتج لدينا: EK1391. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Product Type: Solar Cell / Solar Panel (PV Module)
- Nominal Voltage: 12V
- Rated Current: 125mA
- Rated Power: 1.5W
- Output Type: DC
- Operating Condition (Typical): Vmp ≈ 12V / Imp ≈ 125mA
- Open Circuit Voltage (Voc): 18–22V (typical)
- Short Circuit Current (Isc): 130–160mA (typical)
منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.
تصفّح المزيد من Power Supply في إكوسترا.
Specification
Specification
| WeightWeight | 10 g |
|---|---|
| Dimensions | 5 × 4 × 2 cm |
| Product Type | Solar Cell / Solar Panel (PV Module) |
| Nominal Voltage | 12V |
| Rated Current | 125mA |
| Rated Power | 1.5W |
| Output Type | DC |
| Operating Condition (Typical) | Vmp ≈ 12V, Imp ≈ 125mA |
| Open Circuit Voltage (Voc) | 18–22V (typical) |
| Short Circuit Current (Isc) | 130–160mA (typical) |
