vero board PCB LINE IC FR2 (9X15 cm2) new version

This vero board is an FR2 phenolic paper laminate board pre-etched with parallel copper tracks in an IC/line layout, rather than a plain grid of isolated pads. The parallel track pattern is laid out to match standard DIP IC pin spacing, making it suited for breadboard-style prototyping where components need continuous connection runs along a row.

The board measures 9cm x 15cm (90mm x 150mm) with a thickness of about 1.6mm, and uses the standard 2.54mm (0.1″) hole grid with ~1mm hole diameter — the same pitch used by DIP ICs, headers, and most through-hole components.

Copper tracks run on the single-sided bottom layer, and the FR2 substrate is rated to withstand up to 260°C for standard soldering durations, with flame-retardant classification for added safety during assembly.

Features:

1. Pre-etched parallel copper tracks (IC/line layout)
2. Standard 2.54mm hole pitch, compatible with DIP packages
3. Single-sided copper on FR2 phenolic paper laminate
4. Board size: 9cm x 15cm, ~1.6mm thick
5. Heat-resistant up to 260°C for standard soldering
6. Flame retardant substrate
7. Suits DIP ICs, transistors, resistors, capacitors, and Arduino/DIY circuits
