DC motor GW370 12V with encoder 150 RPM

Name: DC motor GW370 12V with encoder 150 RPM
SKU: EK2069
Price: 750.00 EGP
Availability: InStock

DC Motor GW370 12V with Encoder 150 RPM
1. Voltage: 12V DC
2. Speed: 150 RPM (no-load)
3. Motor Type: DC geared motor
4. Encoder: Incremental quadrature
5. Frame: GW370

SKU: EK2069 Category: DC Motor Tags: 12V motor, 150 RPM, closed-loop, DC Motor, DC motor | محرك تيار مستمر، GW370، محرك 12 فولت، 150 دورة في الدقيقة، محرك مزود بمشفر، مشفر رباعي، محرك روبوتي، حلقة مغلقة, encoder motor, GW370, quadrature encoder, robotic motor
