ESP32 2.8″ TFT Touch Screen Development Board (LVGL)
ESP32 2.8″ TFT Touch Screen Development Board (LVGL)
1. Controller: ESP32-WROOM-32 (Dual-Core)
2. Screen Size: 2.8″ TFT, 240×320
3. Touch Type: Resistive
4. Memory: 4MB Flash | 520KB SRAM
5. Connectivity: Wi-Fi 802.11 b/g/n | Bluetooth 4.2/BLE
Apple Shopping Event
1.500,00 EGP
Payment Methods:
Description
The ESP32 2.8″ TFT Touch Screen Development Board is an HMI development board built around the dual-core ESP32-WROOM-32 controller, paired with a 2.8-inch TFT LCD (typically driven by an ILI9341 controller) at 240×320 resolution with resistive touch input.
Onboard memory covers 4MB of flash and 520KB of SRAM (specs may vary slightly by manufacturer), sufficient for standard LVGL-based UI projects. Wireless connectivity includes 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 4.2/BLE.
Interfaces include USB Type-C or Micro-USB for power and programming, a MicroSD/TF card slot, an onboard RGB LED, and an LDR light sensor. It supports Arduino IDE, LVGL, MicroPython, and ESP-IDF, running on a 5V DC supply.
Features:
- ESP32-WROOM-32 dual-core controller
- 2.8″ TFT resistive touch display, 240×320 resolution (ILI9341 typical)
- 4MB flash, 520KB SRAM
- Wi-Fi 802.11 b/g/n + Bluetooth 4.2/BLE
- Onboard RGB LED and LDR light sensor
- MicroSD/TF card slot for storage expansion
- Supports Arduino IDE, LVGL, MicroPython, ESP-IDF
نظرة عامة ومواصفات المنتج — بالعربية
ESP32 2.8" TFT Touch Screen Development Board (LVGL) متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Development Boards، بسعر 1.500,00 EGP. كود المنتج لدينا: EK2023. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.
أهم المواصفات الفنية:
- Module Type: HMI Smart Display / Development Board
- Main Controller: ESP32-WROOM-32 (Dual-Core 32-bit)
- Screen Size: 2.8 Inch
- Display Panel: TFT LCD
- Display Driver: ILI9341 (Typical)
- Resolution: 240 x 320 Pixels
- Touch Type: Resistive Touch Screen
- Memory: 4MB Flash / 520KB SRAM
هذا المنتج مناسب لمشاريع الأردوينو (Arduino) و ESP32 و Raspberry Pi، ومشاريع الروبوتات وإنترنت الأشياء والتعليم الهندسي. جميع القطع مفحوصة قبل الشحن.
تصفّح المزيد من Development Boards في إكوسترا.
Specification
Specification
| WeightWeight | 10 g |
|---|---|
| Dimensions | 5,5 × 2,8 × 1,2 cm |
| Module Type | HMI Smart Display / Development Board |
| Main Controller | ESP32-WROOM-32 (Dual-Core 32-bit) |
| Screen Size | 2.8 Inch |
| Display Panel | TFT LCD |
| Display Driver | ILI9341 (Typical) |
| Resolution | 240 x 320 Pixels |
| Touch Type | Resistive Touch Screen |
| Memory | 4MB Flash, 520KB SRAM |
| Wireless Connectivity | 2.4GHz Wi-Fi (802.11 b/g/n), Bluetooth 4.2/BLE |
| On-Board Interfaces | USB Type-C or Micro-USB, MicroSD/TF Card Slot, RGB LED, LDR |
| Supported Frameworks | Arduino IDE, LVGL, MicroPython, ESP-IDF |
| Operating Voltage | 5V DC |
