7 Position DIP Switch

This 7-position DIP switch offers a compact, reliable method for configuring electronic circuits via manual binary input. Each of the seven independent SPST slide actuators provides a definitive open or closed state, allowing designers to set addresses, enable options, or adjust system parameters without requiring software or permanent solder connections.

Featuring a standard 0.1-inch (2.54mm) pin spacing, this through-hole component is compatible with common breadboards and PCB layouts. The slide mechanism delivers positive tactile feedback, ensuring the switch state is clearly registered, while the low-profile housing minimizes vertical clearance in dense assemblies.

1. 7-position single-pole single-throw (SPST) slide switch array
2. Standard 0.1 inch (2.54mm) DIP pin spacing for breadboard and PCB compatibility
3. Positive detent actuation with clear open/closed status indication
4. Low-profile epoxy resin body for space-constrained designs
5. Through-hole mounting for reliable mechanical retention
6. Manual configuration eliminates need for external programming hardware
7. Operating temperature range suitable for commercial and industrial applications
