CNC V3 Shield Drivers

Name: CNC V3 Shield Drivers
SKU: aA1631
Price: 125.00 EGP
Availability: OutOfStock

CNC V3 Shield Drivers
1. Compatibility: Arduino UNO
2. Stepper Driver Slots: Up to 4
3. Supported Drivers: A4988, DRV8825
4. Firmware Support: GRBL

SKU: aA1631 Categories: Motor Drivers, Motors | Drivers, Stepper Motors and Accessories Tags: A4988 shield | شيلد A4988, Arduino CNC shield | شيلد اردوينو للسي ان سي, CNC shield | شيلد سي ان سي, DRV8825 shield | شيلد DRV8825, GRBL shield | شيلد GRBL, Motor Drivers, Motors, stepper motor driver board | لوحة درايفر موتور ستيبر, Stepper Motors and Accessories

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

125,00 EGP

Compare

6 People watching this product now!

Payment Methods:

Description

The CNC V3 Shield is an expansion board that stacks directly onto an Arduino UNO to add stepper-motor driving capability, turning the UNO into the control core for CNC machines, laser engravers, 3D printers, and other motion-controlled builds. Instead of wiring stepper drivers to the UNO by hand, the shield provides ready sockets and signal routing for up to four stepper driver modules.

It accepts plug-in driver modules such as the A4988 or DRV8825, letting the builder choose the driver based on the current rating and microstepping resolution their motors need, without changing the shield itself.

The shield is designed for compatibility with GRBL firmware, the widely used open-source CNC motion-control firmware, so builders can flash GRBL onto the Arduino UNO underneath and drive the shield using standard G-code senders.

Features:
1. Direct stack-on expansion for Arduino UNO
2. Supports up to 4 stepper driver modules
3. Compatible with A4988 and DRV8825 driver modules
4. GRBL firmware compatible
5. Suited to CNC machines, laser engravers, and 3D printers
6. Simplifies wiring versus manual stepper driver setups

🔌

Pin Connections

1 Table

Pin Connections Table 1

Board	Sensor Pin	Connection
X-axis driver	STEP/DIR	D2 / D5

📟

CNC V3 Shield Drivers

1 Example • C/C++ | Boards: Arduino Uno

Wrap

CNC V3 Shield Drivers - Arduino Uno

📄 File: cnc_v3_shield_drivers_-_arduino_uno.inoArduino Uno

577 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Fixed CNC Shield V3 mapping: X STEP=D2 DIR=D5, Enable=D8

6#define X_STEP_PIN 2

7#define X_DIR_PIN 5

8#define ENABLE_PIN 8

10void setup() {

11 Serial.begin(115200);

12 pinMode(X_STEP_PIN, OUTPUT);

13 pinMode(X_DIR_PIN, OUTPUT);

14 pinMode(ENABLE_PIN, OUTPUT);

15 digitalWrite(ENABLE_PIN, LOW);

16}

18void loop() {

19 digitalWrite(X_DIR_PIN, HIGH);

20 for (int i = 0; i < 200; i++) {

21 digitalWrite(X_STEP_PIN, HIGH);

22 delayMicroseconds(800);

23 digitalWrite(X_STEP_PIN, LOW);

24 delayMicroseconds(800);

25 }

26 delay(500);

27}

Project Notes:

CNC Shield V3 with driver modules installed - fixed pin mapping.

نظرة عامة ومواصفات المنتج — بالعربية

CNC V3 Shield Drivers متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Motor Drivers وMotors | Drivers وStepper Motors and Accessories، بسعر 125,00 EGP. كود المنتج لدينا: aA1631. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.

أهم المواصفات الفنية:

Base Board Compatibility: Arduino UNO
Stepper Driver Slots: 4
Supported Driver Modules: A4988 / DRV8825
Firmware Compatibility: GRBL
Typical Applications: CNC machines / Laser engravers / 3D printers
الوزن: 4 g

منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.

تصفّح المزيد من Motor Drivers في إكوسترا.

Specification

WeightWeight	40 g
Dimensions	4 × 3 × 3 cm
Base Board Compatibility	Arduino UNO
Stepper Driver Slots	4
Supported Driver Modules	A4988, DRV8825
Firmware Compatibility	GRBL
Typical Applications	CNC machines, Laser engravers, 3D printers
