Digi XBee S2C 802.15.4 RF zigbee module

Name: Digi XBee S2C 802.15.4 RF zigbee module
SKU: EK1342
Price: 1700.00 EGP
Availability: OutOfStock

Digi XBee S2C 802.15.4 RF Zigbee Module
1. Wireless Protocol: IEEE 802.15.4
2. Main Chipset: Silicon Labs EM357
3. Operating Frequency: 2.4 GHz ISM Band
4. Outdoor Line-of-Sight Range: Up to 1200m
5. Communication Interface: UART | SPI
6. Operating Voltage: 2.1V ~ 3.6V DC

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

1.700,00 EGP

Compare

14 People watching this product now!

Payment Methods:

Description

The Digi XBee S2C is a wireless RF transceiver module built around the Silicon Labs EM357 chipset, implementing the IEEE 802.15.4 protocol for point-to-point, point-to-multipoint, and peer-to-peer wireless networking topologies.

Operating in the 2.4GHz ISM band at a 250Kbps RF data rate, it reaches up to 60 meters indoors/urban and up to 1200 meters outdoors line-of-sight, with a transmit power of +3.1dBm and receiver sensitivity of -100dBm in boost mode. It runs on 2.1V–3.6V DC, drawing 33mA on transmit, 28mA on receive, and under 1µA in power-down mode.

Communication with a host is handled over UART or SPI, and the module exposes 15 GPIO lines plus 4 10-bit ADC inputs, letting it act as a remote I/O expander in addition to a wireless link. Antenna options include PCB antenna, U.FL connector, or wire antenna depending on the stock variant.

Features:

IEEE 802.15.4 wireless protocol (Zigbee-class)
Silicon Labs EM357 chipset
2.4GHz ISM band, 250Kbps data rate
Up to 1200m outdoor line-of-sight range
UART/SPI host interface
15 GPIO lines, 4 10-bit ADC inputs
Ultra-low power-down current: <1µA
Operating voltage: 2.1V–3.6V DC

🔌

Pin Connections

1 Table

Pin Connections Table 1

Board	Sensor Pin	Connection
XBee	VCC/GND/DOUT/DIN	3.3V / GND / board RX pin / board TX pin

📟

Digi XBee S2C 802.15.4 RF zigbee module

7 Examples • C/C++ | Boards: Arduino Uno, Arduino Nano, Arduino Mega, ESP32, ESP8266, STM32, Raspberry Pi Pico

Wrap

Digi XBee S2C 802.15.4 RF zigbee module - Arduino Uno

Digi XBee S2C 802.15.4 RF zigbee module - Arduino Nano

Digi XBee S2C 802.15.4 RF zigbee module - Arduino Mega

Digi XBee S2C 802.15.4 RF zigbee module - ESP32

Digi XBee S2C 802.15.4 RF zigbee module - ESP8266

Digi XBee S2C 802.15.4 RF zigbee module - STM32

Digi XBee S2C 802.15.4 RF zigbee module - Raspberry Pi Pico

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_arduino_uno.inoArduino Uno

521 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=2, TX=3 on Arduino Uno. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#include <SoftwareSerial.h>

7SoftwareSerial LINK_SERIAL(2, 3);

9void setup() {

10 Serial.begin(115200);

11 LINK_SERIAL.begin(9600);

12}

14void loop() {

15 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

16 if (Serial.available()) LINK_SERIAL.write(Serial.read());

17}

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_arduino_nano.inoArduino Nano

522 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=2, TX=3 on Arduino Nano. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#include <SoftwareSerial.h>

7SoftwareSerial LINK_SERIAL(2, 3);

9void setup() {

10 Serial.begin(115200);

11 LINK_SERIAL.begin(9600);

12}

14void loop() {

15 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

16 if (Serial.available()) LINK_SERIAL.write(Serial.read());

17}

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_arduino_mega.inoArduino Mega

490 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=19, TX=18 on Arduino Mega. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#define LINK_SERIAL Serial1

8void setup() {

9 Serial.begin(115200);

10 LINK_SERIAL.begin(9600);

11}

13void loop() {

14 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

15 if (Serial.available()) LINK_SERIAL.write(Serial.read());

16}

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_esp32.inoESP32

483 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=16, TX=17 on ESP32. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#define LINK_SERIAL Serial1

8void setup() {

9 Serial.begin(115200);

10 LINK_SERIAL.begin(9600);

11}

13void loop() {

14 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

15 if (Serial.available()) LINK_SERIAL.write(Serial.read());

16}

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_esp8266.inoESP8266

521 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=D7, TX=D8 on ESP8266. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#include <SoftwareSerial.h>

7SoftwareSerial LINK_SERIAL(D7, D8);

9void setup() {

10 Serial.begin(115200);

11 LINK_SERIAL.begin(9600);

12}

14void loop() {

15 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

16 if (Serial.available()) LINK_SERIAL.write(Serial.read());

17}

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_stm32.inoSTM32

486 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=PA10, TX=PA9 on STM32. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#define LINK_SERIAL Serial1

8void setup() {

9 Serial.begin(115200);

10 LINK_SERIAL.begin(9600);

11}

13void loop() {

14 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

15 if (Serial.available()) LINK_SERIAL.write(Serial.read());

16}

📄 File: digi_xbee_s2c_802.15.4_rf_zigbee_module_-_raspberry_pi_pico.inoRaspberry Pi Pico

493 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// RX=1, TX=0 on Raspberry Pi Pico. Configure the XBee's own network settings first via XCTU on a PC (via a USB explorer board), then it acts as a transparent UART bridge to another paired XBee.

6#define LINK_SERIAL Serial1

8void setup() {

9 Serial.begin(115200);

10 LINK_SERIAL.begin(9600);

11}

13void loop() {

14 if (LINK_SERIAL.available()) Serial.write(LINK_SERIAL.read());

15 if (Serial.available()) LINK_SERIAL.write(Serial.read());

16}

Project Notes:

Zigbee mesh-network UART module - configure via XCTU first, then acts as a transparent serial bridge.

نظرة عامة ومواصفات المنتج — بالعربية

Digi XBee S2C 802.15.4 RF zigbee module متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم IoT and Wireless، بسعر 1.700,00 EGP. كود المنتج لدينا: EK1342. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.

أهم المواصفات الفنية:

الموديل: XBee S2C (802.15.4)
Main Chipset: Silicon Labs EM357
Wireless Protocol: IEEE 802.15.4
Operating Frequency: 2.4 GHz ISM Band
Rf Data Rate: 250 Kbps
Indoor/Urban Range: Up to 60 Meters
Outdoor Line Of Sight Range: Up to 1200 Meters
Transmit Power: +3.1 dBm (Boost Mode)

هذا المنتج مناسب لمشاريع الأردوينو (Arduino) و ESP32 و Raspberry Pi، ومشاريع الروبوتات وإنترنت الأشياء والتعليم الهندسي. جميع القطع مفحوصة قبل الشحن.

تصفّح المزيد من IoT and Wireless في إكوسترا.

Specification

WeightWeight	10 g
Dimensions	5 × 4 × 2 cm
Model	XBee S2C (802.15.4)
Main Chipset	Silicon Labs EM357
Wireless Protocol	IEEE 802.15.4
Operating Frequency	2.4 GHz ISM Band
RF Data Rate	250 Kbps
Indoor/Urban Range	Up to 60 Meters
Outdoor Line-of-Sight Range	Up to 1200 Meters
Transmit Power	+3.1 dBm (Boost Mode)
Receiver Sensitivity	-100 dBm (Boost Mode)
Operating Voltage	2.1V ~ 3.6V DC
Current Consumption (TX)	33mA at 3.3V
Current Consumption (RX)	28mA at 3.3V
Current Consumption (Power-down)	<1µA
Communication Interface	UART, SPI
Digital I/O Pins	15 GPIO Lines
Analog Inputs	4x 10-bit ADC
