FS1000A 433mHz Tx & Rx RF Radio Module

Name: FS1000A 433mHz Tx &amp; Rx RF Radio Module
SKU: EK465
Price: 50.00 EGP
Availability: OutOfStock

SKU: EK465 Category: IoT and Wireless Tag: IoT and Wireless

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

50,00 EGP

Compare

7 People watching this product now!

Payment Methods:

Description

This is FS1000A 433mHz Tx RF Radio Module. This RF module comprises an RF Transmitter and an RF Receiver. The transmitter/receiver (Tx/Rx) pair operates at a frequency of 433 MHz. An RF transmitter receives serial data and transmits it wirelessly through RF through its antenna connected at pin4. The transmission occurs at the rate of 1Kbps – 10Kbps. The transmitted data is received by an RF receiver operating at the same frequency as that of the transmitter. This low-cost RF transmitter can be used to transmit signals up to 100 meters (the antenna design, working environment, and supply voltage will seriously impact the effective distance). It’s good for a short distance, battery power device development. 433 MHz is the operating frequency for transmitter and receiver pair. <hr /> <h4>Features :</h4> <ol> <li>Wide input supply (2.5 V to 12V)</li> <li>Easy to integrate (V+, GND, and Data)</li> <li>The device in deep sleep mode when Data pin is grounded</li> <li>Very small dimension.</li> </ol> <hr /> <h5>Receiver Module specification</h5> <a href=""https://robu.in/wp-content/uploads/2016/05/FS1000A-433mHz-Receiver-ROBU.IN_.jpg""><img class=""size-full wp-image-188299 aligncenter"" src=""https://robu.in/wp-content/uploads/2016/05/FS1000A-433mHz-Receiver-ROBU.IN_.jpg"" alt=""FS1000A 433mHz Receiver -ROBU.IN"" width=""266"" height=""178"" /></a> Operation voltage: DC5V Static Current: 4MA Receiver frequency: 433.92MHZ; 315 Mhz Sensitivity：－105DB Dimension：30*14*9mm External Antenna：32CM signal wire，spiral <h5>Transmitter Module Specification</h5> <a href=""https://robu.in/wp-content/uploads/2016/05/FS1000A-433mHz-Transmitter-ROBU.IN_.jpg""><img class=""size-full wp-image-188305 aligncenter"" src=""https://robu.in/wp-content/uploads/2016/05/FS1000A-433mHz-Transmitter-ROBU.IN_.jpg"" alt=""FS1000A 433mHz Transmitter – ROBU.IN"" width=""174"" height=""178"" /></a> Operating voltage: 3-12V Operating frequency: 433.92MHz; 315Mhz Standby current: 0mA Operating current :20-28mA Transmission distance:> 500m (open to receiving plate sensitivity at-103dBm distance of more than) Output Power: 16dBm (40mW) Transfer rate: <10Kbps Modulation mode: OOK (Amplitude Modulation) Operating Temperature: -10 ℃ ~ +70 ℃ Size: 19 × 19 × 8mm <hr /> <h4>Package Includes :</h4> 1 x FS1000A 433mHz Transmitter. 1 x FS1000A 433mHz Receiver.

🔌

Pin Connections

1 Table

Pin Connections Table 1

Board	Sensor Pin	Connection
FS1000A TX	VCC/GND/DATA	5V / GND / board digital pin

📟

FS1000A 433mHz Tx & Rx RF Radio Module

7 Examples • C/C++ | Boards: Arduino Uno, Arduino Nano, Arduino Mega, ESP32, ESP8266, STM32, Raspberry Pi Pico

Wrap

FS1000A 433mHz Tx & Rx RF Radio Module - Arduino Uno

FS1000A 433mHz Tx & Rx RF Radio Module - Arduino Nano

FS1000A 433mHz Tx & Rx RF Radio Module - Arduino Mega

FS1000A 433mHz Tx & Rx RF Radio Module - ESP32

FS1000A 433mHz Tx & Rx RF Radio Module - ESP8266

FS1000A 433mHz Tx & Rx RF Radio Module - STM32

FS1000A 433mHz Tx & Rx RF Radio Module - Raspberry Pi Pico

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_arduino_uno.inoArduino Uno

414 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin 11 on Arduino Uno (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(11);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_arduino_nano.inoArduino Nano

415 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin 11 on Arduino Nano (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(11);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_arduino_mega.inoArduino Mega

415 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin 11 on Arduino Mega (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(11);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_esp32.inoESP32

408 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin 17 on ESP32 (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(17);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_esp8266.inoESP8266

410 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin D8 on ESP8266 (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(D8);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_stm32.inoSTM32

410 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin PA6 on STM32 (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(PA6);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

📄 File: fs1000a_433mhz_tx_&_rx_rf_radio_module_-_raspberry_pi_pico.inoRaspberry Pi Pico

420 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Data pin 19 on Raspberry Pi Pico (simple ASK/OOK transmitter - pairs with an FS1000A/XY-MK-5V receiver on the other end)

6#include <RCSwitch.h>

8RCSwitch mySwitch = RCSwitch();

10void setup() {

11 mySwitch.enableTransmit(19);

12}

14void loop() {

15 mySwitch.send(5393, 24); // an arbitrary 24-bit code - match to your receiver/remote's real code

16 delay(1000);

17}

Project Notes:

Simple ASK/OOK 433MHz transmitter (paired with a matching receiver module).

Required Libraries:

rc-switchGitHub

نظرة عامة ومواصفات المنتج — بالعربية

FS1000A 433mHz Tx & Rx RF Radio Module متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم IoT and Wireless، بسعر 50,00 EGP. كود المنتج لدينا: EK465. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.

أهم المواصفات الفنية:
