Water Level Depth Detection Sensor for Arduino

Measures water level or depth using pressure or ultrasonic sensing
Provides analog or digital output compatible with Arduino
Easy integration with microcontrollers for real-time monitoring
Suitable for tanks, wells, or reservoirs
Durable and waterproof design for reliable use in wet environments
Operates at 3.3V to 5V power supply

SKU: EK405 Categories: Sensors, Water TDS, pH, Flow, Level and Pressure Sensor Tags: 3-5V Water Sensor, Analog Water Level Sensor, Arduino, Arduino Water Sensor, Cost-Effective Water Sensor, Depth Detection Sensor, Easy-to-Use Water Sensor, Sensors, Water Detection Module, Water Level Alarm Sensor, Water Level Sensor, Water Sensor for Arduino, Water TDS, pH, Flow, Level and Pressure Sensor, Water Volume Measurement.

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

30,00 EGP

Compare

6 People watching this product now!

Payment Methods:

Description

The Water Level Depth Detection Sensor for Arduino has Operating voltage DC3-5V and Operating current less than 20mA. The Sensor is the Analog type which produces analog output signals according to the water pressure with its Detection Area of 40x16mm.

The Water Level Sensor is an easy-to-use and cost-effective with high level/drop recognition sensor by having a series of parallel wires exposed traces measure droplets/water volume in order to determine the water level.

Easy to complete water to analog signal conversion and output analog values can be directly read Arduino development board to achieve the level alarm effect.

Package Includes :

1 x Water Level Sensor Depth of Detection Water Sensor for Arduino

🔌

Pin Connections

1 Table

Pin Connections Table 1

Board	Sensor Pin	Connection
Water Level Sensor	VCC/GND/SIG	3.3-5V / GND / board analog pin

📟

Water Level Depth Detection Sensor for Arduino

7 Examples • C/C++ | Boards: Arduino Uno, Arduino Nano, Arduino Mega, ESP32, ESP8266, STM32, Raspberry Pi Pico

Wrap

Water Level Depth Detection Sensor for Arduino - Arduino Uno

Water Level Depth Detection Sensor for Arduino - Arduino Nano

Water Level Depth Detection Sensor for Arduino - Arduino Mega

Water Level Depth Detection Sensor for Arduino - ESP32

Water Level Depth Detection Sensor for Arduino - ESP8266

Water Level Depth Detection Sensor for Arduino - STM32

Water Level Depth Detection Sensor for Arduino - Raspberry Pi Pico

📄 File: water_level_depth_detection_sensor_for_arduino_-_arduino_uno.inoArduino Uno

482 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin A0 on Arduino Uno. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN A0

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 5.0 / 1023.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

📄 File: water_level_depth_detection_sensor_for_arduino_-_arduino_nano.inoArduino Nano

483 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin A0 on Arduino Nano. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN A0

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 5.0 / 1023.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

📄 File: water_level_depth_detection_sensor_for_arduino_-_arduino_mega.inoArduino Mega

483 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin A0 on Arduino Mega. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN A0

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 5.0 / 1023.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

📄 File: water_level_depth_detection_sensor_for_arduino_-_esp32.inoESP32

476 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin 34 on ESP32. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN 34

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 3.3 / 4095.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

📄 File: water_level_depth_detection_sensor_for_arduino_-_esp8266.inoESP8266

478 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin A0 on ESP8266. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN A0

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 3.3 / 1023.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

📄 File: water_level_depth_detection_sensor_for_arduino_-_stm32.inoSTM32

478 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin PA0 on STM32. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN PA0

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 3.3 / 4095.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

📄 File: water_level_depth_detection_sensor_for_arduino_-_raspberry_pi_pico.inoRaspberry Pi Pico

488 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// Analog pin 26 on Raspberry Pi Pico. Traces on the sensor board act as a variable resistor - more submersion = lower resistance = higher reading.

6#define WATER_PIN 26

8void setup() {

9 Serial.begin(115200);

10}

12void loop() {

13 int raw = analogRead(WATER_PIN);

14 float voltage = raw * 3.3 / 4095.0;

16 Serial.print("Water level raw: "); Serial.print(raw);

17 Serial.print(" Voltage: "); Serial.println(voltage);

19 delay(500);

20}

Project Notes:

Analog resistive water-level strip.

نظرة عامة ومواصفات المنتج — بالعربية

Water Level Depth Detection Sensor for Arduino متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم Sensors وWater TDS, pH, Flow, Level and Pressure Sensor، بسعر 30,00 EGP. كود المنتج لدينا: EK405. المنتج متوفر في المخزون وجاهز للشحن الفوري لكل محافظات مصر مع إمكانية الدفع عند الاستلام.

أهم المواصفات الفنية:

Model Type: Water Level Sensor Length (mm): 60 Width (mm): 20 Height (mm): 1.5 Weight (g): 4
جهد التشغيل (فولت): 3 to 5
Max Operating Current Ma: 20
Detection Range: 40×16 mm
Operating Temperature C: -10 to 30
Operating Humidity: 10% -90% non-condensing
الوزن: 6 g

هذا المنتج مناسب لمشاريع الأردوينو (Arduino) و ESP32 و Raspberry Pi، ومشاريع الروبوتات وإنترنت الأشياء والتعليم الهندسي. جميع القطع مفحوصة قبل الشحن.

تصفّح المزيد من Sensors في إكوسترا.

Specification

WeightWeight	6 g
Dimensions	60 × 20 × 15 cm
operating-voltage-vdc	3 to 5
max-operating-current-ma	20
detection-range	40×16 mm
operating-temperature-c	-10 to 30
operating-humidity	10% -90% non-condensing
