2.4GHz Wireless Transceiver nRF 24L01 (85 meter)

Name: 2.4GHz Wireless Transceiver nRF 24L01 (85 meter)
SKU: NRF2401
Price: 65.00 EGP
Availability: OutOfStock

nRF24L01 2.4GHz wireless transceiver with up to 2Mbps and ultra-low power.

SKU: NRF2401 Category: IoT and Wireless Tags: 2.4GHz wireless, 2Mbps transceiver, IoT and Wireless, ISM band module, low power RF, nRF24L01 | nRF24L01، لاسلكي 2.4GHz، جهاز إرسال واستقبال RF، وحدة لاسلكية، جهاز إرسال واستقبال 2Mbps، وحدة نطاق ISM، RF منخفض الطاقة، لاسلكي SPI, RF transceiver, SPI wireless, wireless module

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

65,00 EGP

Compare

4 People watching this product now!

Payment Methods:

Description

The nRF24L01 2.4GHz Wireless Transceiver Module is a highly integrated, ultra-low-power RF solution for the 2.4GHz ISM band. Operating at up to 2Mbps with GFSK modulation for excellent efficiency and interference resistance, this module is particularly suitable for industrial control and wireless communication applications.

With peak RX/TX currents below 14mA and a sub-μA power-down mode, the nRF24L01 provides exceptional power management for battery-operated devices. Built-in hardware CRC error detection ensures reliable data transmission, while the 1.9 to 3.6V supply range supports various power sources. Its multi-purpose antenna design delivers stable communication over significant distances.

🔌

Pin Connections

1 Table

Pin Connections Table 1

Board	Sensor Pin	Connection
nRF24L01	VCC/GND/CE/CSN	3.3V only / GND / board digital pin / board digital pin

📟

2.4GHz Wireless Transceiver nRF 24L01 (85 meter)

7 Examples • C/C++ | Boards: Arduino Uno, Arduino Nano, Arduino Mega, ESP32, ESP8266, STM32, Raspberry Pi Pico

Wrap

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - Arduino Uno

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - Arduino Nano

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - Arduino Mega

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - ESP32

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - ESP8266

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - STM32

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) - Raspberry Pi Pico

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_arduino_uno.inoArduino Uno

499 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=9, CSN=10 on Arduino Uno (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(9, 10);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_arduino_nano.inoArduino Nano

500 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=9, CSN=10 on Arduino Nano (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(9, 10);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_arduino_mega.inoArduino Mega

500 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=9, CSN=10 on Arduino Mega (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(9, 10);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_esp32.inoESP32

491 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=4, CSN=5 on ESP32 (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(4, 5);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_esp8266.inoESP8266

497 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=D3, CSN=D8 on ESP8266 (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(D3, D8);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_stm32.inoSTM32

499 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=PB0, CSN=PA4 on STM32 (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(PB0, PA4);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

📄 File: 2.4ghz_wireless_transceiver_nrf_24l01_(85_meter)_-_raspberry_pi_pico.inoRaspberry Pi Pico

507 characters

1//ekostra.com

2//electronics store in egypt

3//+201008896258

5// CE=20, CSN=17 on Raspberry Pi Pico (MOSI/MISO/SCK use the board's default hardware SPI pins)

6#include <SPI.h>

7#include <RF24.h>

9RF24 radio(20, 17);

10const byte address[6] = "1Node";

12void setup() {

13 Serial.begin(115200);

14 radio.begin();

15 radio.openWritingPipe(address);

16 radio.setPALevel(RF24_PA_LOW);

17 radio.stopListening();

18}

20void loop() {

21 const char text[] = "Hello from Ekostra";

22 radio.write(&text, sizeof(text));

23 delay(1000);

24}

Project Notes:

SPI 2.4GHz transceiver - very popular for Arduino-to-Arduino wireless links.

Required Libraries:

RF24 (nRF24)GitHub

نظرة عامة ومواصفات المنتج — بالعربية

2.4GHz Wireless Transceiver nRF 24L01 (85 meter) متوفر الآن في متجر إكوسترا للإلكترونيات، ضمن قسم IoT and Wireless، بسعر 65,00 EGP. كود المنتج لدينا: NRF2401. المنتج غير متوفر حالياً — تواصل معنا عبر واتساب لمعرفة موعد توفره القادم.

أهم المواصفات الفنية:

Item Type: Wireless Module
الموديل: NRF24L01
Frequency: 2400 MHz (2.4GHz)
Data Rate: Up to 2Mbps
Modulation: GFSK
Supply Voltage: 1.9 ~ 3.6V
التيار: RX/TX < 14mA
Features: Hardware CRC error detection

منتج أصلي بجودة مضمونة من إكوسترا، مع دعم فني ومتابعة بعد البيع لكل عملائنا في مصر.

تصفّح المزيد من IoT and Wireless في إكوسترا.

Specification

WeightWeight	10 g
Dimensions	5 × 4 × 2 cm
Item Type	Wireless Module
Model	NRF24L01
Frequency	2400 MHz (2.4GHz)
Data Rate	Up to 2Mbps
Modulation	GFSK
Supply Voltage	1.9 ~ 3.6V
Current	RX/TX < 14mA
Features	Hardware CRC error detection
